Emerson KJ3225X1-BA1 12P4174X032 Resistance Input Card
Product Introduction
The Emerson KJ3225X1-BA1 12P4174X032 is a highly reliable resistance input card that is part of the DeltaV series, known for its exceptional precision in monitoring and control of resistance-based sensors. This input card is designed to interface with sensors like RTDs (Resistance Temperature Detectors) and other resistance-based sensors, providing accurate data for process control and automation systems.
With a compact design and a robust build, the KJ3225X1-BA1 card offers seamless integration into DeltaV distributed control systems (DCS). It is capable of processing resistance inputs and converting them into readable signals for temperature, pressure, or other process measurements, making it ideal for industrial environments where reliability and accuracy are critical.
The card is easy to install and features advanced diagnostics, making maintenance straightforward. It supports up to 12 channels of resistance input, offering flexibility for multi-channel applications. Whether for monitoring temperature in a chemical reactor or controlling a pressure vessel, this input card ensures reliable, real-time data for optimal performance.
Parameters
| Parameter | Specification |
|---|---|
| Model | KJ3225X1-BA1 12P4174X032 |
| Input Type | Resistance Input (RTD, Thermistor, etc.) |
| Number of Channels | 12 Channels |
| Dimensions | 107 x 41 x 105 mm |
| Weight | 0.2 kg |
| Power Supply | 24V DC |
| Accuracy | ±0.1% of Full Scale |
| Temperature Range | -200°C to +850°C (for RTD) |
| Supported Sensors | RTD, Thermistor |
| Isolation | 1500V Isolation |
| Communication Protocol | HART, Modbus |
| Mounting Type | DIN Rail Mountable |
| Operating Temperature | -40°C to +70°C |
| Protection Class | IP20 |
Applications
The Emerson KJ3225X1-BA1 12P4174X032 resistance input card is primarily used in industrial applications that require accurate temperature and pressure monitoring. It is widely used in process industries, including oil and gas, chemicals, power generation, and food processing, for the following applications:
-
Temperature Control: The card interfaces with RTDs or thermistors to monitor and control the temperature of various processes such as reactors, furnaces, and heat exchangers.
-
Pressure Monitoring: By interfacing with resistance-based pressure sensors, it helps monitor pressure levels in tanks, pipes, or boilers.
-
Process Automation: It enables real-time monitoring of critical process variables, ensuring systems operate within safe limits and improving overall system efficiency.
-
Temperature Compensation: In systems where temperature affects the accuracy of pressure measurements or other sensor readings, this card helps compensate for temperature changes, ensuring more precise data.
Advantages
The Emerson KJ3225X1-BA1 12P4174X032 provides a wide range of advantages for users:
-
High Accuracy and Reliability: With an accuracy of ±0.1% of full scale, it delivers precise and consistent results for critical measurements.
-
Wide Temperature Range: Capable of handling a wide temperature range from -200°C to +850°C for RTDs, it is suitable for diverse industrial applications.
-
Multiple Channel Support: The card supports up to 12 resistance input channels, offering flexibility for multi-sensor systems.
-
Seamless Integration: It integrates effortlessly into the DeltaV system, providing smooth operation and compatibility with other DeltaV components.
-
Easy Installation and Maintenance: With a DIN rail mounting design and advanced diagnostic capabilities, the card is easy to install, maintain, and troubleshoot.
-
Advanced Signal Processing: The card can process a variety of resistance-based sensors and convert them into actionable data for process control.
Brand and Series
-
Brand: Emerson
-
Series: DeltaV Series
Related Models in the Same Series or Category
| Model | Description | Number of Channels | Temperature Range | Applications |
|---|---|---|---|---|
| KJ3201X1-BA1 | Voltage Input Card | 8 Channels | -10°C to +60°C | General control systems |
| KJ3223X1-BA1 | Thermocouple Input Card | 8 Channels | -200°C to +1800°C | Temperature measurement |
| KJ3245X1-BA1 | Current Input Card | 16 Channels | -40°C to +70°C | Current measurement |
| KJ3212X1-BA1 | Digital Input Card | 16 Channels | -40°C to +70°C | On/off control systems |
| KJ3230X1-BA1 | Strain Gauge Input Card | 8 Channels | -200°C to +850°C | Pressure and strain monitoring |
Popular Emerson Models
| Model | Description | Channels | Measurement Type | Applications |
|---|---|---|---|---|
| KJ3225X1-BA1 | Resistance Input Card | 12 Channels | RTD, Thermistor | Process control and monitoring |
| KJ3223X1-BA1 | Thermocouple Input Card | 8 Channels | Thermocouple | Temperature measurement |
| KJ3245X1-BA1 | Current Input Card | 16 Channels | Current Loop | Analog signal processing |
| KJ3212X1-BA1 | Digital Input Card | 16 Channels | Digital Input | Digital control systems |
| KJ3230X1-BA1 | Strain Gauge Input Card | 8 Channels | Strain Gauge | Structural health monitoring |
FAQs
Q: What type of sensors does the KJ3225X1-BA1 support?
A: The KJ3225X1-BA1 supports resistance-based sensors, including RTDs and thermistors.
Q: What is the number of channels supported by this card?
A: The card supports up to 12 resistance input channels.
Q: What is the accuracy of the KJ3225X1-BA1?
A: The accuracy is ±0.1% of full scale.
Q: What is the temperature range for RTD sensors on this card?
A: The card supports RTD sensors with a temperature range of -200°C to +850°C.
Q: How does the KJ3225X1-BA1 connect to a DeltaV system?
A: It integrates directly into the DeltaV distributed control system (DCS) for easy monitoring and control.
Q: Is the KJ3225X1-BA1 suitable for high-temperature environments?
A: Yes, it is capable of handling temperatures up to 850°C for RTDs.
Q: What is the weight of the KJ3225X1-BA1 card?
A: The card weighs 0.2 kg.
Q: Can I use this card in hazardous environments?
A: Yes, it is designed for industrial environments, though additional certifications may be required for hazardous areas.
Q: How is the KJ3225X1-BA1 mounted?
A: The card mounts easily on a DIN rail, making installation quick and straightforward.
Q: What is the isolation level of this card?
A: The card features 1500V isolation to protect the system from electrical faults.
Reliable Precision for Your Process Control
Ensure the accuracy and longevity of your industrial systems with the Emerson KJ3225X1-BA1 resistance input card. Its precision and multi-channel capabilities make it the perfect choice for process control.
Efficiency Starts with Accurate Data
Gain real-time insights with the KJ3225X1-BA1, a resistance input card that simplifies your monitoring process and enhances operational efficiency.
Future-Proof Your Control Systems
With the KJ3225X1-BA1, you’re investing in the future of automation. Its advanced capabilities ensure your systems stay ahead in today’s dynamic industrial environments.
Seamless Integration for Optimal Performance
Integrate the KJ3225X1-BA1 into your DeltaV system effortlessly and experience unmatched reliability and flexibility for process control applications.
