Product Overview for Schneider 170AMM09000 Distributed Analog/Digital I/O Module
Brand: Schneider Electric
Series: Modicon Momentum Series
Product Type: Distributed Analog/Digital I/O Module
Product Code: 170AMM09000
Product Introduction
The Schneider 170AMM09000 is a versatile distributed I/O module that provides both analog and discrete input/output capabilities for industrial automation systems. Part of the Modicon Momentum series, it is designed to facilitate seamless communication between field devices and control systems. This module is essential for applications where both analog and digital signals need to be monitored and controlled efficiently.
With its high-density I/O configuration, the 170AMM09000 module can manage a wide range of inputs and outputs, making it suitable for a variety of industrial automation tasks, from process control to machinery monitoring. It supports easy integration with the Modicon Momentum control platform, offering a reliable and cost-effective solution for modular and scalable control systems.
Product Parameters
| Parameter | Specification |
|---|---|
| Product Dimensions | 47.5 x 125 x 141.5 mm |
| Weight | 0.24 kg |
| Input Types | 4 analog inputs, 4 digital inputs |
| Output Types | 4 analog outputs, 4 digital outputs |
| Power Supply | 24 VDC |
| Temperature Range | -10°C to 60°C |
| Input/Output Resolution | 12-bit resolution for analog I/O |
| Communication Interface | Modbus |
| Mounting | DIN rail |
| Operating Humidity | 5% to 95% non-condensing |
| Certifications | UL, CE, cULus |
Applications
The 170AMM09000 module is designed for a wide range of applications in various industries:
-
Industrial Automation: Ideal for systems requiring both analog and digital I/O for process control, monitoring, and automation tasks.
-
Machine Control: Provides effective management of discrete sensors and actuators as well as continuous analog signals for industrial machinery.
-
Building Automation: Used in smart building systems for controlling HVAC systems, lighting, and other essential infrastructure.
-
Energy Management: Perfect for monitoring and controlling electrical systems, including power distribution and consumption.
-
Water Treatment: Applied in process control systems within water treatment plants, where both analog and discrete signals are required for accurate measurement and control.
Advantages
-
High Flexibility: Supports both analog and digital I/O, offering versatile solutions for different types of control applications.
-
Compact Design: The module has a compact form factor, making it ideal for systems with limited space and a need for high-density I/O.
-
Seamless Integration: Fully compatible with Modicon Momentum controllers, allowing easy integration into existing systems without the need for additional hardware.
-
Scalability: Can be expanded as needed, making it suitable for small systems as well as large, complex applications.
-
Robust Performance: With its wide temperature and humidity range, the 170AMM09000 is built to withstand harsh industrial environments, ensuring reliable operation over time.
-
Cost-Effective: Provides a cost-efficient solution for applications requiring both analog and discrete I/O without compromising on performance.
Recommended Related Models in the Modicon Momentum Series
| Model | Description | Channels | Input Types | Output Types |
|---|---|---|---|---|
| 170AMM09010 | Distributed analog/digital I/O module | 8 | Analog, Digital | Analog, Digital |
| 170AMM09001 | High-density distributed I/O module | 16 | Analog, Digital | Analog, Digital |
| 170AMM09011 | Compact distributed I/O module | 4 | Analog, Digital | Analog, Digital |
| 170AMM09020 | Advanced I/O module with communication | 12 | Analog, Digital | Analog, Digital |
| 170AMM09030 | Flexible I/O module for industrial use | 16 | Analog, Digital | Analog, Digital |
Other Popular Schneider Models
| Model | Description | Channels | Input Types | Output Types |
|---|---|---|---|---|
| 140CRA31200 | Digital I/O module | 16 | Digital | Digital |
| 140DAO84200 | Analog output module | 8 | Analog | Analog |
| 140DRA84000 | Digital relay output module | 8 | Digital | Digital |
| 140CPS11400 | Power supply for Modicon controllers | N/A | N/A | N/A |
| 140CPU11303 | Modicon processor unit | N/A | N/A | N/A |
FAQ (Frequently Asked Questions)
Q1: What is the power supply requirement for the 170AMM09000 module?
A1: The 170AMM09000 requires a 24 VDC power supply.
Q2: How many channels does the 170AMM09000 support for analog and digital I/O?
A2: The module supports 4 analog inputs, 4 analog outputs, 4 digital inputs, and 4 digital outputs.
Q3: What is the operating temperature range for the 170AMM09000?
A3: The module operates within a temperature range of -10°C to 60°C.
Q4: What is the resolution of the analog I/O in the 170AMM09000?
A4: The analog I/O has a 12-bit resolution.
Q5: How does the 170AMM09000 communicate with the rest of the system?
A5: The module uses the Modbus communication protocol for integration with control systems.
Q6: What is the weight of the 170AMM09000 module?
A6: The module weighs 0.24 kg.
Q7: Can the 170AMM09000 module be mounted on a DIN rail?
A7: Yes, it is designed for DIN rail mounting.
Q8: What certifications does the 170AMM09000 module have?
A8: The module is UL, CE, and cULus certified.
Q9: What is the humidity range in which the 170AMM09000 can operate?
A9: The module can operate in environments with 5% to 95% non-condensing humidity.
Q10: Can the 170AMM09000 module be used in high-density applications?
A10: Yes, the module is ideal for high-density I/O applications with its compact design and ability to manage multiple analog and digital signals.
Maximize Your Control with Schneider’s 170AMM09000 I/O Module
Take control of your industrial processes with Schneider’s versatile 170AMM09000 module, offering flexible analog and digital I/O for a wide range of applications.
Seamless Integration, Unmatched Performance
Experience effortless integration with Modicon Momentum controllers and superior performance in every environment with the 170AMM09000 I/O module.
Compact, Reliable, and Efficient
Designed for space-saving without compromising on performance, the 170AMM09000 offers high-density I/O capabilities in a compact and reliable module.
Simplify Your System with Schneider’s Distributed I/O Solutions
Schneider’s 170AMM09000 module simplifies your control system by managing both analog and digital I/O efficiently, making it a key part of your industrial automation strategy.
