Schneider BMXFTB2020 20-Pin Removable Spring Terminal Block
Product Description:
The Schneider BMXFTB2020 is a 20-pin removable spring terminal block, designed specifically for the Modicon X80 series of I/O modules. This terminal block offers a spring-type connection system for easy installation and secure connections. The spring terminal technology enables tool-free wiring, providing users with faster and more efficient setup in industrial automation systems.
The BMXFTB2020 is engineered to provide reliable electrical connections for a variety of industrial applications, where secure and vibration-resistant connections are required. The spring mechanism ensures consistent pressure, maintaining reliable contact over time and minimizing the risk of connection failure, even under challenging conditions.
Its compact size and modular design make it highly suitable for control panels, automation systems, and distributed control systems where space efficiency and easy maintenance are essential. The BMXFTB2020 is durable, robust, and designed to withstand the demands of industrial environments.
Specifications:
| Feature |
Specification |
| Model Number |
BMXFTB2020 |
| Series |
Modicon X80 |
| Type |
20-pin removable spring terminal block |
| Number of Connections |
20 |
| Connection Type |
Spring terminals (tool-free wiring) |
| Wire Size Compatibility |
0.2 mm² to 2.5 mm² (24 to 14 AWG) |
| Rated Voltage |
Up to 250V AC/DC |
| Rated Current |
Up to 10A per connection |
| Dimensions |
91.4 x 41.8 x 32 mm |
| Weight |
0.093 kg |
| Mounting Type |
Direct plug-in for Modicon X80 modules |
| Insulation Material |
High-durability thermoplastic |
| Color |
Black |
| Operating Temperature |
-25°C to 70°C |
| Storage Temperature |
-40°C to 85°C |
| Vibration Resistance |
IEC 60068-2-6 Compliant |
| Standards Compliance |
IEC 61131-2, UL, CSA, CE |
Applications:
The BMXFTB2020 spring terminal block is used in a variety of industrial and automation applications where quick and secure wiring is required. Its tool-free connection makes it ideal for environments where easy maintenance and rapid installation are essential. Typical applications include:
-
Industrial Automation Systems: Ensures reliable I/O connections for Programmable Logic Controllers (PLC) and Distributed Control Systems (DCS).
-
Control Panels: Suitable for compact control cabinets, offering a neat and efficient wiring solution.
-
Power Distribution: Used in switchgear panels, providing secure electrical connections in power management systems.
-
Factory Automation: Perfect for robotics, machinery control, and sensor wiring in automated manufacturing plants.
-
Building Management Systems (BMS): Ideal for lighting control, HVAC, and security systems, ensuring effective wiring in smart buildings.
Advantages:
-
Spring Terminal Technology – The spring terminal design enables tool-free wiring, significantly reducing installation time and improving maintenance efficiency.
-
Easy Installation and Removal – The removable nature of the terminal block allows for quick adjustments and easy repairs, especially in dynamic environments.
-
High Electrical Ratings – Rated for 250V AC/DC and up to 10A per connection, making it suitable for high-power applications.
-
Compact Design – Its small footprint of 91.4 x 41.8 x 32 mm makes it perfect for space-constrained installations.
-
Vibration Resistance – Built to withstand harsh industrial environments, the BMXFTB2020 is IEC 60068-2-6 compliant, ensuring resilience against vibrations.
-
Modular Integration – Designed to seamlessly integrate with the Modicon X80 series for easy expansion and customization of control systems.
-
Wide Wire Compatibility – Supports wire sizes from 0.2 mm² to 2.5 mm² (24-14 AWG), offering flexibility in wire selection.
-
Durable Construction – Made from high-quality thermoplastic insulation, ensuring long-lasting performance even in demanding conditions.
-
Cost-Efficient Solution – The tool-free installation and reduced maintenance costs make it a cost-effective solution for industrial applications.
-
Compliance with Standards – Meets IEC, UL, CSA, and CE standards, ensuring it adheres to global safety and performance requirements.
Brand Information:
Schneider Electric is a global leader in energy management and automation, providing innovative solutions to help businesses achieve greater efficiency, sustainability, and productivity. The Modicon X80 series is part of their scalable I/O systems, designed for industrial automation, control, and process monitoring. Schneider’s solutions are trusted worldwide for their reliability, performance, and ease of integration.
Recommended Models from the Same Series:
| Model |
Description |
Dimensions |
Weight |
| BMXFTB2000 |
20-pin removable screw terminal block |
91.4 x 41.8 x 32 mm |
0.093 kg |
| BMXFTB2010 |
20-pin removable screw terminal block |
91.4 x 41.8 x 32 mm |
0.093 kg |
| BMXFTB2030 |
20-pin removable spring terminal block |
91.4 x 41.8 x 32 mm |
0.093 kg |
| BMXFTB2040 |
40-pin removable spring terminal block |
91.4 x 41.8 x 32 mm |
0.095 kg |
| BMXFTB2050 |
20-pin high-density removable spring terminal block |
91.4 x 41.8 x 32 mm |
0.093 kg |
